Nickle
Master Metal offers high-performance Nickel and Nickel Alloy products known for their outstanding corrosion resistance, heat resistance, and mechanical strength. We supply grades such as Nickel 200, 201, Alloy 400 (Monel), Alloy 600, 625, 800, 825 (Inconel/Incoloy) suitable for extreme environments. Nickel is widely used in chemical processing, marine, aerospace, oil & gas, and power generation industries. Our product range includes sheets, plates, rods, tubes, pipes, fittings, and flanges, all conforming to ASTM, ASME, and DIN specifications. With consistent quality and precision, Master Metal delivers nickel solutions that perform reliably in the most demanding applications.
Equivalent
| Alloy | British Standard | Werkstoff Nr | UNS Designation |
|---|---|---|---|
| Ni 200/201 | BS 3075 (NA11) | 2.4060 | N02200 / N02201 |
| Ni 205 / 205 LC | – | 2.4061 | N02205 |
Chemical Compositions
| Alloy | Ni | Mn | Fe | Si | Cu | C | Ti |
|---|---|---|---|---|---|---|---|
| Ni 200 | Min 99.2 | Max 0.30 | Max 0.20 | Max 0.10 | Max 0.20 | Max 0.10 | Max 0.10 |
| Ni 201 | Min 99.2 | Max 0.30 | Max 0.20 | Max 0.10 | Max 0.20 | Max 0.05 | Max 0.10 |
| Ni 205 | Min 99.6 | Max 0.20 | Max 0.20 | Max 0.10 | Max 0.10 | Max 0.05 | Max 0.05 |
| Ni 205 LC | Min 99.6 | Max 0.20 | Max 0.20 | Max 0.10 | Max 0.10 | Max 0.02 | Max 0.05 |
Mechanical Properties
| Alloy | Tensile Strength (N/mm²) | Elongation % at L₀ = 100 mm | ||
|---|---|---|---|---|
| Min | Max | Min | Max | |
| Ni 200 / 201 | 400 | 550 | 20 | 30 |
| Ni 205 / 205 LC | 400 | 530 | 20 | 30 |
